制氧机
Oxygen concentrator
CJ-ZYJ-01 医用制氧机
模块化集成式制氧机的设计过程充分考虑了用户的实际需求。整机采用高度集成的设计，去掉了诸如空气压缩机和氧气生成模块等部件。这些部件被整合到一个单一的底盘中，从而减少了整个氧气生成系统所占用的地面空间。安装方式灵活便捷，大大节省了现场安装时间。它适用于中小型医疗设施，是医疗机构安全使用氧气的理想选择。
参数：
氧气生成:10M3/H
氧气浓度: >93%+3%
输出电压: 0.25-0.75MPa
输入电压: AC380V
额定功率: 9KW
设备尺寸: 1720mm*1000mm*1900mm
噪音:<55dB
上述数据是基于实验室环境测试得出的。在实际应用中，由于环境差异可能会出现轻微的波动。具体条款需依据合同约定而定。
制氧机产品
L I S
产品简介
Product introduction
Characteristics:
1.It has the function of remote monitoring via a mobile phone APP
2. The air compressor, filter and oxygen generator are designed as an integrated unit
3. Real-time display of operating status, historical data, and various operating parameters
4. Variable frequency design, energy-saving and highly efficient
5. Equipped with a PLC programmable controller
6. Special molecular sieves for oxygen production are adopted, which result in
a higher oxygen separation rate and better adsorption effect
7. According to the user's requirements, customize dedicated air source systems and electrical control systems
